Description
Powerful, Versatile, Field-Ready
Experience brilliant 1500nits high brightness, rugged yet lightweight design, and a complete toolset for professional monitoring.
The new SVM-130P delivers outstanding visibility in any environment with 1500nits high brightness, slim & rugged build, and broadcast-level monitoring features including 12G-SDI in/out, waveform & vectorscope, picture-by-picture, and custom 3D LUTs.
Dimensions
Main Body: 376.8 x 302.5 x 130 (mm) / 14.83 x 11.90 x 5.11 (inch)
Weight: 5.34kg / 11.77lbs
Product Highlights
- 1500nits High Brightness Display
- 2 x 12G-SDI Input and Loopout
- 12G-SDI Input to 3G-SDI Downscale Output
- Processed Monitor Output
- Cheese Plates, C-stand Mountable
- Dual Battery Brackets (V-Mount, G-Mount)
- Picture-by-Picture Display
- HDR (PQ, HLG, S-LOG3)
- Custom 3D LUT Import by USB Flash Drive
- Auto Detection of SDI Payload ID
- Image Capture & Overlay
- Waveform (YCbCr, RGB) / Vector Scope / Histogram
- Audio Level Meter / Audio Phase Meter
- Fast Mode
- Focus Assist / Marker
- Blue/Mono Only / Timecode Display
- Remote Control & FW Update via Ethernet
- H Flip, V Flip
Shipping specifications
| Brand | TVLogic |
|---|---|
| Itemcode | 2605.0357 |
| Bruto weight | 35 |
| Net weight | 24 |
| HS code | 8528529100 - Monitors |
| Shipping dimensions | 110 x 41 x 88 cm |
| Supplier item code | TVL-SVM-130P |
